Lens Disassembly Tool

Link Metal CNC Fiber Laser Lens Disassembly Tool for Laser Cutting Heads

Professional industrial grade fiber laser lens disassembly tool, exclusively designed for mainstream fiber laser cutting heads and welding heads. This tool is a dedicated maintenance accessory for laser equipment, which can quickly and safely disassemble and install collimating lens, focusing lens and pressure rings, effectively avoid damage to optical lenses, threads and AR coating during disassembly, reduce equipment downtime, it is an essential tool for daily maintenance and repair of fiber laser equipment.

Key Advantages

  • Precision CNC machined aviation aluminum body, 1:1 perfectly matches original cutting head structure, tight fit, no slippage, no damage to lens pressure ring and internal threads
  • High strength anodic oxidation surface treatment, wear-resistant, corrosion-resistant, no burrs, will not scratch the optical lens and anti-reflection coating, extend the service life of the lens
  • Ergonomic design, labor-saving operation, quick disassembly and installation, greatly improve maintenance efficiency, reduce equipment downtime and maintenance costs
  • Full series of special models available, 1:1 OEM fit for RayTools, Precitec, WSX, OSPRI mainstream brand cutting heads, plug and play, no additional adjustment required
  • Universal models cover 15-55mm lens caliber, compatible with most fiber laser cutting heads and welding heads on the market, one tool for multiple purposes

Compatible Models

RayTools

  • BM109/BT210S
  • BM110/BM111
  • BM114/BM114S
  • BM115
  • BT240/BTS240S

Precitec

  • 1.0 Collimating & Focusing Lens
  • 1.0 Middle Protective Focusing Pressure Ring
  • 1.0 Special Collimating Pressure Ring
  • 2.0 Series

WSX (Wanshunxing)

  • NC30/K13/NC12/K15 Mini Focusing Lens
  • NC30/K13/NC12/K15 Mini Collimating Lens
  • NC30/K13/NC12/K15 Mini Collimating & Focusing Lens
  • NC/NC60 Series

Other Compatible Brands

  • CQWY (Chaoqiang Weiye): Handheld Laser Welding Head
  • RECI: Disassembly Tool with Disassembly Blade & Screws
  • OSPRI: LC80, LC20S, LSHW200, LW410, LS40
  • Universal: Disassembly Tool Set, 15-55mm Disassembly Wrench

For custom models, please contact our sales team directly.

Specifications

  • Brand: Link Metal CNC
  • Compatible Brand: RayTools, Precitec, WSX, CQWY, RECI, OSPRI, Universal
  • Product Type: Special Lens Disassembly Tool / Universal Disassembly Tool Set / Universal Disassembly Wrench
  • Main Material: High-Grade Aviation Aluminum
  • Surface Treatment: Hard Anodic Oxidation
  • Applicable Equipment: Fiber Laser Cutting Machines, Handheld Laser Welding Machines
  • Applicable Wavelength: 1064nm

Package Includes

  • 1 x Selected Lens Disassembly Tool / Tool Set / Wrench
  • 1 x Specialized Dust-Proof Shockproof Protective Packaging

Quality Assurance

All fiber laser lens disassembly tools from Link Metal CNC undergo strict size testing and fit inspection before delivery, with stable performance and reliable quality, we provide professional after-sales support for all products.
